Capacitive insulator CG3-40.5-163x320
Technical specifications:
Parameter
Value
Rated operating voltage**, kV
40.5
Maximum operating voltage**, kV
40.5
One-minute power-frequency withstand voltage, kV
92
Creepage distance, mm
>840
Bending strength*, kN
>8
Mass*, kg
<6.8
Embedded capacitor capacitance**, pF
10 or 40
Climatic version, placement category
Temperate and cold climate, category 2
Upon customer's request:
*The parameter depends on the thread and material of embedded parts.
**The parameter depends on the capacitance of the embedded capacitor.
- Possibility of changing the thread and material of embedded parts.
- Possibility of changing the capacitance of the embedded capacitor.
