Capacitive insulator CG3-24-80x226
Technical specifications:
Parameter
Value
Rated operating voltage**, kV
24
Maximum operating voltage**, kV
24
One-minute power-frequency withstand voltage, kV
65
Creepage distance, mm
>390
Bending strength*, kN
>2
Mass*, kg
<1.4
Embedded capacitor capacitance**, pF
60
Climatic version, placement category
Temperate and cold climate, category 2
Upon customer's request:
*The parameter depends on the thread and material of embedded parts.
**The parameter depends on the capacitance of the embedded capacitor.
- Possibility of changing the thread and material of embedded parts.
- Possibility of changing the capacitance of the embedded capacitor.
