Capacitive insulator CG3-12-80x130
Technical specifications:
Parameter
Value
Rated operating voltage**, kV
12
Maximum operating voltage**, kV
12
One-minute power-frequency withstand voltage, kV
42
Creepage distance, mm
>240
Bending strength*, kN
>5
Mass*, kg
<0,9
Embedded capacitor capacitance**, pF
120
Climatic version, placement category
Temperate and cold climate, category 2
Upon customer's request:
*The parameter depends on the thread and material of embedded parts.
**The parameter depends on the capacitance of the embedded capacitor.
- Possibility of changing the thread and material of embedded parts.
- Possibility of changing the capacitance of the embedded capacitor.
*The parameter depends on the thread and material of embedded parts.
**The parameter depends on the capacitance of the embedded capacitor.
