Limit switch F10
Application
F10 is a rotary limit switch (auxiliary contacts) designed for switching secondary circuits of operating mechanisms.
Design
It is a rotary switch consisting of stacked insulated sections connected by a square-section shaft. Each section consists of a NO+NC contact group separated from the others by a plastic housing.
Technical specifications:
Parameter
Value
Maximum switching voltage
380 V AC
220 V DC
220 V DC
Frequency
50 Hz
Maximum current
10 A (220 V AC)
6 A (110 V DC)
4 A (220 V DC)
6 A (110 V DC)
4 A (220 V DC)
Contact resistance
ess than 50 mOhm
