HST/CST series cable terminations for shielded single-core and three-core cables with plastic insulation for 12, 24 and 40.5 kV indoor and outdoor installation
Cable terminations are used for terminating single-core and three-core shielded power cables with PVC insulation, with or without armor.
Example of designation: HST-I-12/3-(150-240)-650 – Indoor heat-shrinkable cable termination for 12 kV voltage, for a three-core cable with a cross-section of 150-240 mm², termination length – 650 mm.
The terminations comply with the requirements of IEC 60502-4
Example of designation: HST-I-12/3-(150-240)-650 – Indoor heat-shrinkable cable termination for 12 kV voltage, for a three-core cable with a cross-section of 150-240 mm², termination length – 650 mm.
The terminations comply with the requirements of IEC 60502-4
Types of installed cables
N(A)2XS2Y, N(A)2XSY, N(A)2XSEYBY, N(A)2XSYBY, N(A)2XS(F)2Y, N(A)2XS(FL)2Y, N(A)2XY, N(A)YSEY, N2XSEY, AXEKVCY, AXEKVCEY
Classification of terminations by shrinkage type
HST series heat-shrinkable cable terminations
Table of HST series termination executions
CST series cold-shrinkable cable terminations
Table of CST series termination executions
Cold-shrinkable cable terminations are a new product among cable terminations, manufactured using highly elastic silicone. This product has special dielectric properties, resistance to tracking and corrosion, constant shrinkage force, and does not lose its insulating properties even with severe cable bending. Installation of such a termination does not require a heat gun or any special tools.
