Cable T-Adapters 7.2-24 kV RICS
Insulating RICS T-Adapters 7.2-24 kV are used to connect single-core and three-core cables with plastic insulation to Interface C bushings according to EN 50181 of solid insulated, gas-insulated, and dry (clean) air-insulated switchgear for 7.2-24 kV for urban transformer substations and distribution transformer substations, providing their reliable sealing, insulation, and electrical connection. They are made of high-quality elastomer resistant to moisture, dust, heat, and cold. They are used together with cable joints of POLT, 1PKVTp-12, 3PKVTp-12, 1PKVTp-24 types.
Kit Contents
If necessary, a CTR (Cable Testing Rod) can be added to the kit.
RICS kit 12 kV
RICS kit 24 kV
Cable cross-section is selected from the range: 70, 95, 120, 150, 185, 240, 300 mm².
Ordering example: RICS 24-70/150 – Insulating T-adapter RICS design for connecting a cable from the cross-section range of 70-150 mm².
Ordering example: RICS 24-70/150 – Insulating T-adapter RICS design for connecting a cable from the cross-section range of 70-150 mm².
Examples of RICS cable adapter application in 12 kV networks
Examples of RICS cable adapter application in 24 kV networks
