Bushing TGN-12-140x200

Download PDF drawing — TGN-12-140x200

Technical specifications:

Parameter
Value
Nominal operating voltage, kV
12
Maximum operating voltage, kV
12
Power-frequency 1 min withstand voltage, kV
42
Weight, kg
4,1
Climatic version, placement category
Temperate and cold climate, category 2
Upon customer's request:

  • possibility of manufacturing slots of various sizes;
  • possibility of changing the thread and material of embedded parts.
The parameter depends on the shape of the bushing slot, thread and material of embedded parts.
Download PDF drawing — TGN-12-140x200
